Victron’s Phoenix inverters have been developed for professional use and can be used for various applications. The inverters have hybrid HF technology that combines exceptional specifications and capabilities with light weight and small dimensions.
An important feature is the high peak power, which makes the inverters suitable for devices that require high starting power such as refrigerators, freezers, electric motors and air conditioners.
In addition, 2 to 6 inverters can be connected in parallel, so that a higher output power can be achieved. With 6 parallel connected Phoenix Phoenix 24/5000 inverters, this output power is 24kW / 30kVA.
All Phoenix inverters with a capacity of 1200VA or more have an interactive RS-485 connection. With the VEConfigure software and the MK2 RS-485 to RS232 interface, all parameters can be easily set and read.
The Phoenix inverters can also be connected to the Victron VENet network or to other computer-controlled management systems. This can be done by using an RS-232 to USB conversion cable.
Specifications
Capacity | 2000VA |
---|---|
Type of inverter | Victron inverter 230V |
System voltage (DC) | 12VDC |
Output voltage (AC) | 230VAC |
Built-in power socket | No |
Length | 520 mm |
Width | 255 mm |
Height | 125 mm |
Weight | 12.00 kg |
